Specification

• Electronic variable 4 speed push button control
• Extraction mode: A ducting kit is attached to the hood to extract the cooking vapours externally, giving a pleasant kitchen environment, which is free from cooking odours.
• Recirculation or extraction options
• For installation into an island chimney or corner unit

Performance

• Fluid dynamic efficiency class: D
• Lighting efficiency class: A
• Capacity minimum, m3/h: 295
• Capacity, Max m³/h: 600

Installation

• Installation: Group
• Dimensions, HxWxD: 245-245x700x285
• Minimum distance from electric cooking top: 50
• Minimum distance from gas cooking top: 65
• Required Fuse: No
• Colour: Stainless steel

Energy

• Frequency: 50
• Energy class: C
• Grease filter efficiency class: C
• Sound power min speed, dB(A): 49
• Sound power max speed, dB(A): 63
• Recirc sound power min, dB(A): 60
• Recirc sound power max, dB(A): 70
• Recirculation min, m3/h: 215
• Recirculation max, m3/h: 350

Other

• Product number (PNC): 942 022 067
• Size: 70
• Cord Length: 1
• Voltage: 220-240
• Charcoal filter type: ECFB02
• Superperforming charcoal filter compatible: NO, NO
• No. of speed settings: 4
• Lamp type: LED spotlight
• No. of lamps: 2
• Grease filters: 2
