SPECIFICATION

• 4 cooking zones
• Front controls: The controls have been placed at the front of the hob to enable quick, safe, easy access.
• Residual heat indicators: This safety feature visually indicates when residual heat is left on the hob surface.
• 9 stage digital power level displays
• Child safety control lock: To maximise kitchen safety, this lock can be activated to prevent the hob from being turned on accidentally.
• Auto safety switch off: If a cooking zone is left on, the power automatically cuts out after a set period of time.
• Front left zone: Dual Hilight® zone
• Front right zone: Single Hilight® zone
• Rear left zone: Single Hilight® zone
• Rear right zone: Single Hilight® zone

PERFORMANCE

• Dial: 750/2200W/120/210mm
• Rear - Power/Diameter: 1200W/145mm
• Right front - Power/Diameter: 1200W/145mm
• Right rear - Power/Diameter: 1800W/180mm

INSTALLATION

• Hobs Dimensions: 590x520
• Aperture dimensions HxWxD in mm: 38x560x490
• Radius cutting: 5
• Gas replacement: No
• Gas replacement: No

ENERGY

• Total electricity loading, W: 6400

OTHER

• Product number (PNC): 949 492 160
• Cord Length: 0
• Hob safety: Automatic Switch Off
• Gas supply: natural gas: No
• Residual heat indicator: 7 Segments
• Led Colour: Red
